帶有行星齒輪的氣動馬達

帶有行星齒輪的氣動馬達

該原理基于行星齒輪。驅動通過太陽輪，輸出通過行星架，三個行星輪布置在行星架上。外輪也是變速箱的一部分。由于三個行星齒輪的對稱布置，在每個位置都形成了中央摩擦連接。劃分扭矩，以便甚至可以可靠地控制峰值扭矩。由于這種設計，在行星齒輪組中會產生純扭矩。扭轉剛度大大提高。該優點使得可以制造緊湊的，減輕重量的裝置。對稱的行星齒輪布置和較高的制造精度使運轉非常平穩。



高精度風葉電機主要由帶有轉子軸的轉子，殼體，軸承蓋，散熱片，滾子軸承和密封環組成。轉子縮回到轉子軸上。四個或八個散熱片可在轉子的高精度滑動槽中自由移動，并支撐在珩磨的外殼孔上。在啟動和低速行駛期間，板條壓力的解決方式有所不同：通過板條支撐環，彈簧或從后部加壓。在更高的速度下，離心力還可以支撐薄片密封。根據速度，壓縮空氣條件和工作壓力，薄片的使用壽命為數千個工作小時。板條磨損后會自動調整。尺寸大為8AM，轉子浮動在固定在軸承蓋中的滾動軸承中，而16AM壓縮空氣馬達的軸承則根據浮動軸承原理進行求解。對于浮動軸承，通過滾動軸承配合來規定和限制轉子軸上的軸向允許載荷。為了不危害浮動軸承的優點，必須避免在轉子軸上施加軸向載荷。進氣和排氣通過殼體中的連接螺紋供應。通過使入口和出口反向，可逆壓縮空氣馬達中的旋轉方向可以反向。轉子軸通過密封圈與大氣隔離

Specken-Drumag液壓氣缸產品分類：

Specken-Drumag RIBA比例控制器

Specken-Drumag 液壓缸

Specken-Drumag Specken-Drumag 液壓氣動系統

Specken-Drumag speedPOWER - 按壓氣缸

Specken-Drumag speedPOWER - 電動缸

Specken-Drumag 電動缸

Specken-Drumag 氣動缸

Specken-Drumag 旋轉執行器

Specken-Drumag 閥門

Specken-Drumag 壓縮機/ Vacuumpumps

Specken-Drumag 壓縮空氣處理

Specken-Drumag 氣動馬達

Specken-Drumag 消音器

Specken-Drumag RS200

Specken-Drumag 80 ZLS

Specken-Drumag 3V4-EF-V

Specken-Drumag ZLA-C-SHA 50/60-D-N

Specken-Drumag RP500

Specken-Drumag 3V4-EF-V

Specken-Drumag 258SD

Specken-Drumag ZHS-A 36

Specken-Drumag RP300

Specken-Drumag R41-CB-R00

Specken-Drumag 3V4-EF-V

Specken-Drumag 258SD

Specken-Drumag 4AM-FRV-63A

Specken-Drumag 4AM-NRV-22B-P120.

SPECKEN-DRUMAG液壓氣缸型號：

ZAR系列：

ZAR-FBv 25/125 NHR15 D-U01 E31，

ZU系列：

ZU-Fv 32/140 NHR16 D-H03 E11g G1/4“ ES As4，

ZISO/T系列：

ZISO/T-RFv 32漢18達250 Dbb森H03 E22 ES，

ZU,250系列：

ZU250-G?

ZHSS系列

主要產品介紹：

Hydaira液壓氣缸：

ZAR系列(活塞直徑10-25mm,工作壓力至63bar，6種密封模式，6種固定方式，不銹鋼)

ZU系列(活塞直徑10-100mm,工作壓力至100bar，8種密封模式，12種固定方式)

ZISO/T系列(活塞直徑25-100mm,工作壓力至160bar，4種密封模式，11種固定方式)

ZU250系列(活塞直徑20-100mm,工作壓力至250bar，4種密封模式，11種固定方式)

ZHSS系列(活塞直徑16-50mm,工作壓力至400bar，原型緊湊結構，3種固定方式)

氣動氣缸：

氣動伸縮式氣缸(兩級和三級，直徑32-63mm,雙向作用，6bar時大活塞力為750N)

帶測距系統的氣缸

氣缸(M系列迷你氣缸8 ÷ 25 mm，Z系列八角迷你氣缸16 ÷ 25 mm，32 ÷ 63 mm，K/KD系類氣缸32 ÷200 mm，R系列旋轉驅動32 ÷ 125 mm，RP/RO緊湊型氣缸32 ÷ 63 mm，RS/PQ系列緊湊型氣缸，RT系列兩級和三級伸縮式氣缸 32 ÷ 63 mm，W系列短行程缸 12 ÷ 100 mm，OV系列橢圓形氣缸 50 ÷ 63 mm)

閥門：

B系列納米閥門 10mm

A系列微型閥門 15mm

AA/AB系列微型先導閥2/2 - 3/2

AC系列螺紋連接閥門MIXED 5/2 DN

Specken-Drumag液壓氣缸產品分類：

Specken-Drumag RIBA比例控制器

Specken-Drumag 液壓缸

Specken-Drumag Specken-Drumag 液壓氣動系統

Specken-Drumag speedPOWER - 按壓氣缸

Specken-Drumag speedPOWER - 電動缸

Specken-Drumag 電動缸

Specken-Drumag 氣動缸

Specken-Drumag 旋轉執行器

Specken-Drumag 閥門

Specken-Drumag 壓縮機/ Vacuumpumps

Specken-Drumag 壓縮空氣處理

Specken-Drumag 氣動馬達

Specken-Drumag 消音器

Specken-Drumag RS200

Specken-Drumag 80 ZLS

Specken-Drumag 3V4-EF-V

Specken-Drumag ZLA-C-SHA 50/60-D-N

Specken-Drumag RP500

Specken-Drumag 3V4-EF-V

Specken-Drumag 258SD

Specken-Drumag ZHS-A 36

Specken-Drumag RP300

Specken-Drumag R41-CB-R00

Specken-Drumag 3V4-EF-V

Specken-Drumag 258SD

Specken-Drumag 4AM-FRV-63A

Specken-Drumag 4AM-NRV-22B-P120.

SPECKEN-DRUMAG液壓氣缸型號：

ZAR系列：

ZAR-FBv 25/125 NHR15 D-U01 E31，

ZU系列：

ZU-Fv 32/140 NHR16 D-H03 E11g G1/4“ ES As4，

ZISO/T系列：

ZISO/T-RFv 32漢18達250 Dbb森H03 E22 ES，

ZU,250系列：

ZU250-G?

ZHSS系列

主要產品介紹：

Hydaira液壓氣缸：

ZAR系列(活塞直徑10-25mm,工作壓力至63bar，6種密封模式，6種固定方式，不銹鋼)

ZU系列(活塞直徑10-100mm,工作壓力至100bar，8種密封模式，12種固定方式)

ZISO/T系列(活塞直徑25-100mm,工作壓力至160bar，4種密封模式，11種固定方式)

ZU250系列(活塞直徑20-100mm,工作壓力至250bar，4種密封模式，11種固定方式)

ZHSS系列(活塞直徑16-50mm,工作壓力至400bar，原型緊湊結構，3種固定方式)

氣動氣缸：

氣動伸縮式氣缸(兩級和三級，直徑32-63mm,雙向作用，6bar時大活塞力為750N)

帶測距系統的氣缸

氣缸(M系列迷你氣缸8 ÷ 25 mm，Z系列八角迷你氣缸16 ÷ 25 mm，32 ÷ 63 mm，K/KD系類氣缸32 ÷200 mm，R系列旋轉驅動32 ÷ 125 mm，RP/RO緊湊型氣缸32 ÷ 63 mm，RS/PQ系列緊湊型氣缸，RT系列兩級和三級伸縮式氣缸 32 ÷ 63 mm，W系列短行程缸 12 ÷ 100 mm，OV系列橢圓形氣缸 50 ÷ 63 mm)

閥門：

B系列納米閥門 10mm

A系列微型閥門 15mm

AA/AB系列微型先導閥2/2 - 3/2

AC系列螺紋連接閥門MIXED 5/2 DN

主要產品：

Specken-Drumag ZLA-C-G 50/30-D-N

Specken-Drumag ZLA-C-SHA 36/70-D-N

Specken-Drumag ZLA-C-H 36/40-D-N

Specken-Drumag ZLA-C-H 50/ 30-D-N HS?

Specken-Drumag ZLA-C-H 70/40-D-N

Specken-Drumag ZLA-C-FV 70/120-D-P-R Pneumatic Cylinder

Specken-Drumag ZLA-C-FV 70/45-D-N-

Specken-Drumag ZLA-C-G 140漢635-D-N-R-

Specken-Drumag 36 ZLA-C Seal Kit

Specken-Drumag 50 ZLA-C Seal Kit

Specken-Drumag 70 ZLA-C

Specken-Drumag PZS-A 63/400-D-P-382

Specken-Drumag ZLS-A 250/10-D-N

Specken-Drumag ZLS-A 50/350-D-N-WMS-PL1-RS 200-

Specken-Drumag ZLS-A 50/250-D-N-WMS-PL1-RS 200-

Specken-Drumag ZLS-A 50/250-D-N-WMS-PL1-RS 200

Specken-Drumag ZLS-A 50/250-D-N-WMS-PL1-RS 200-

Specken-Drumag ZLS-SHA 63/241-D-N-FB-GG-WMS- RS 100

Specken-Drumag ZLS-SHA 63/267-D-N-FB-GG-WMS- RS 100

Specken-Drumag ZLS-A 50/250-D-N-WMS-PL3-RS

Specken-Drumag ZLS-A 50/350-D-N-WMS-PL3-RS

Specken-Drumag ZLS-A 50/350-D-N-WMS-PL3-RS 200

Specken-Drumag ZLS-SM 200達200-D-N-E-GS-WMS-

Specken-Drumag ZLS-SM 320森250-D-N-GS-WM

Specken-Drumag 80 ZLS

Specken-Drumag 100 LZ Seal Kit CO: EC

Specken-Drumag ZLS-SM 200

Specken-Drumag 2AM-NRV-89-P120

Specken-Drumag P81.4 Gear XX

Specken-Drumag DSO-P 63/90-BN-P-E

Specken-Drumag DSO-P 125漢80-S-P-H

Specken-Drumag DSO-P 125/90-S-P-H

Specken-Drumag DSO-P 125/90-S-P-H

Specken-Drumag DSO-P 100/45-S-N-H

Specken-Drumag DSO-P 125/15-BN-N-H rotary actuator

Specken-Drumag DSO-P 125/15-BN-N-H rotary actuator DSO range rotary actuator

Specken-Drumag DSO-P 100/45-S-N-H

Specken-Drumag DSO-P 100/45-S-N-H Rotary Actuator

Specken-Drumag DSO-P 63/350-S-P-29

Specken-Drumag DSO-P 63/180-B-P-E DSO rotary actuator

Specken-Drumag DSO-P 63/210-B-P-E DSO rotary actuator P pneumatic operating mode

Specken-Drumag DSO-P 80/140-S-P-H

Specken-Drumag DSO-P 63/370-BN-P-H-E-ATEX G Rotary Actuator

Specken-Drumag 100 DSO/RAD-P seal kit

Specken-Drumag 125 DSO/RAD-P Sealing Kit

Specken-Drumag 80 DSO/RAD-P (VITON)

Specken-Drumag HPL-C 55-80

Specken-Drumag HPL-B 51-63

Specken-Drumag 63-51 HPL-B seal kit Orign: EU

Specken-Drumag Seal Kit 50 ZUB

Specken-Drumag ZU-G 32/100-D-H01-A1 (NHR15)

Specken-Drumag ZU-G 16/25-D-H01-As1 (NHR12)

Specken-Drumag ZU-G 16/25-D-H01-As1 (NHR12)

Specken-Drumag ZU-KH 20/120-Ez-H00-A1

Specken-Drumag ZU-KH2-10/90-D-H00-As4 spez Connection below

Specken-Drumag ZU250-H2 20/75 D-H00-G1/4-A1

Specken-Drumag ZU250-H2 20/75-Dbb-H00-G1/4-As1

Specken-Drumag ZU250-H2 20/75-Dbb-H00-G1/4-As1

Specken-Drumag Seal Kit D161-H50-D00 (ZU-50/D-H00)

Specken-Drumag Seal Kit D194-H16-E00 (ZHSS 16)

Specken-Drumag HPZL-A 40/5-D-N
