Rotech閥門回訊器MBX41PA2
TCR級是與我們的客戶緊密合作開發的。與普通技術相比，纖薄的設計為用戶提供了很多優勢。
技術數據
尺寸：144*64*70（不帶視覺信標），160*62*80（帶視覺信標）
房屋：vestamid(基地），Macrolon/維斯塔米德/鋁（封面）
防護等級：IP65(帶呼吸膜），IP67/IP68(不帶呼吸膜）
細節
超博設計，但可以安裝4個微型，2個插槽式或2個接近開關
防震和防踩踏電纜入口，防漢電纜密封套
底座的下部設有通風和除氣膜，可避免因溫度差異而出汗。
防爆等級
借助內置的微動開關或傳感器，可以在氣體防爆區域1和2（類別2G和3G）以及粉塵防爆區域21和22（類別2D和3D）中使用。 對于粉塵防爆區域21，還需要使用安全性更高的版本（Ex e）的外殼。
環境溫度
低溫設計：最大-25°攝氏度
最高溫度100°攝氏度
證書和批準
EAC ,SIL2
產品變體
外殼蓋：密閉蓋(馬龍，馬甲，鋁），視覺面板或視覺信標（黃色/紅色）
軸：不銹鋼（1.4305） oder工藝 塑料（POM）
電纜密封套數量：系統連接1*M20*1.5,電磁閥連接1*M12*1.5
夾鉗：最大10個端子排1.5mm2
Rotech 限位開關、球閥限位開關 、回訊器、行程反饋開關、傳感器
Rotech 產品型號：
Rotech MBX30PN2
Rotech MBX31PN2
Rotech MBX32PN2
Rotech MBX33PN2
Rotech MBX34PN2
Rotech MBX35PN2
Rotech MBX36PN2
Rotech MBX37PN2
Rotech MBX38PN2
Rotech MBX39PN2
Rotech MBX3APN2
Rotech MBX3BPN2
Rotech MBX3CPN2
Rotech MBX3DPN2
Rotech MBX40PA2
Rotech MBX3FPN2
Rotech MBX3GPN2
Rotech MBX3HPN2
Rotech TU4DSAPMVSAZ
Rotech PFF25EMVSAZ
Rotech PF5251MVSAZ
Rotech TPFN412EMVSAZ
Rotech TPFN412EAVSAZ
Rotech TPF2V3EMVSAZ
Rotech TPF3NMSVAZ
Rotech TTU5SNASVAZ
Rotech TPFF25NMVSAZ
Rotech TPFF25NVVSAZ
Rotech TPFF25NAVSAZ
Rotech TCR1VVAZ
Rotech TCR1AVAZ
Rotech TPF3NMVSAZ
Rotech TCR3MVAZ
Rotech PCR3MVAZ
Rotech PCR8MVAZ
Rotech MBX40PA2
Rotech MBX41PA2
Rotech MBX42PA2
Rotech MBX43PA2
Rotech MBX44PA2
Rotech MBX45PA2
Rotech MBX46PA2
Rotech MBX47PA2
Rotech MBX48PA2
Rotech MBX49PA2
Rotech MBX10EM2
Rotech MBX10PM2
Rotech MBX20EX2
Rotech MBX50MP2
Rotech PCR3VVAZ
Rotech PPFF25EPMVAZ
Rotech PPFF25ESMVAZ
Rotech PPFF25EPVVAZ
Rotech PPFF25NSMVAZ
Rotech PPF2V3NMVAZ
Rotech CR3MAZ
Rotech CR8MAZ
Rotech PFN412EVAZ
Rotech PF3NAAZ
Rotech PF5SNAAZ
Rotech 188-SUIZRIWK
Rotech ZR236-IIZ
Rotech 3SES200-ID
Rotech 1F5225OAZIER
Rotech PFF25NOAZER
Rotech PFF25EOAZER
Rotech TU4DAOAZIER
Rotech KDM12G4PG9
Rotech PFF31EKKOAZ1
Rotech ROTECH-0001 開關 TCR3MVAZ
Rotech ROTECH-0002 PCR3MVAZ 限位開關
Rotech ROTECH-0003 TPF3NVVAZM12+支架80*30*20
Rotech ROTECH-0004 PF3NVFAZO+支架80*30*20
Rotech ROTECH-0005 80*30*20 不銹鋼的
Rotech ROTECH-0006 PF3NVFAZO
Rotech ROTECH-0007 TCR1WAZ TCR-Modul Crouzet 83
Rotech ROTECH-0008 反饋開關
Rotech ROTECH-0009 ModelNr:TPFF25EMVAZM12
Rotech ROTECH-0010 PCR3SVAZ
Rotech ROTECH-0011 TCR3MVSAZ
Rotech ROTECH-0012 PPF25NPVVAZ
Rotech ROTECH-0013 PE4000
Rotech ROTECH-0014 TPFF25EMVAZM12
Rotech ROTECH-0015 NCN3-F25F-N4P SN:75650097
Rotech ROTECH-0016 HPPF2V3Em VAZ15 PB-Modul
Rotech ROTECH-0017 PPRF25NPSVAZ
Rotech ROTECH-0018 CR3AAZ0 83.161.3
Rotech ROTECH-0019 MBX44PA2
Rotech ROTECH-0020 TCR3MVAZK SN:60828092
Rotech ROTECH-0021 PCR3MVAZ
Rotech ROTECH-0022 TCR1VVAZ 防爆型限位器
Rotech ROTECH-0023 PF3NVAZ
Rotech ROTECH-0024 PF518MNVFAZ
Rotech ROTECH-0025 800-A00-000
Rotech ROTECH-0026 HPPF3V324MVAZ30
Rotech ROTECH-0027 HPPF2V3EMVAZ30
Rotech ROTECH-0028 HPPF2V3EMVAZ15
Rotech ROTECH-0029 TCR1WAZ 限位開關
Rotech ROTECH-0030 AUE-400
Rotech ROTECH-0031 PF3EAAZ
Rotech ROTECH-0032 83.161.301W2
Rotech ROTECH-0033 PAR3MVAZ
Rotech ROTECH-0034 PPFF25NSMVAZ
Rotech ROTECH-0035 TCR3MVA2K
Rotech ROTECH-0036 ALS-200DA,5-240V,300MA,10W
Rotech ROTECH-0037 TCR8MVAZ2M12
Rotech ROTECH-0038 TCR3WVSAZ
Rotech ROTECH-0039 CR3MAZ
Rotech ROTECH-0040 LIMIT SWITCH TPFF25EMVAZ
Rotech ROTECH-0041 TIF5249MVAZ
Rotech ROTECH-0042 TPF2V3EMVAZ
Rotech ROTECH-0043 PPF2V3EMVAZSPX
Rotech ROTECH-0044 PCR8SVAZ
Rotech ROTECH-0045 APL210
Rotech ROTECH-0046 TCR1VVAZ TPYE:83.139.1
Rotech ROTECH-0047 TPFN412EMVAZ SER:102045001
Rotech ROTECH-0048 TCR3MVAZ GROUZET
Rotech ROTECH-0049 TCRSMVAAZZ(83.161.301)
Rotech ROTECH-0050 TPF2V3EMVSAZ
Rotech ROTECH-0051 PFF25EAAZ2
Rotech ROTECH-0052 PFF25EAAZ2SCG551A001MS
Rotech ROTECH-0053 PFF25EAAZ2控制器與SCG551A001MS
Rotech ROTECH-0054 HPPF2V3EMVAZ15
