CALLAN TECHNOLOGY-SEM-MT 30-系列電機等效物原裝進口
CALLAN TECHNOLOGY-電機
扭矩(牛米)2.0 至 6.0
電壓直流 (V)80 至 140
速度 (RPM)4000
框架尺寸（？毫米）108
軸直徑（？毫米）16j6
相同的電機軸和安裝尺寸（IEC 和 NEMA 選項）
• 匹配的電機繞組
• 兼容的扭矩/速度性能
• 匹配的連接選項
• 24/90 V DC 或 115V AC 制動選項
• 匹配測速發電機輸出
• 可用的編碼器選項
• 匹配的非驅動端接口選項
• 稀土磁鐵
• 堅固的機械設計
* MT 是英國 SEM Ltd 的商品名，有刷直流伺服電機
CALLAN TECHNOLOGY-型號：
SEM Callan Technology
CALLAN TECHNOLOGY-SEM-MT30E4-52 M4-2950 M
CALLAN TECHNOLOGY-SEM-MT30E4-32 M4-2950 Q
CALLAN TECHNOLOGY-SEM-MT30E4-25 M4-2950 S
CALLAN TECHNOLOGY-SEM-MT30E4-20 M4-2950 A
CALLAN TECHNOLOGY-SEM-MT30F4-52 M4-2950 M
CALLAN TECHNOLOGY-SEM-MT30F4-45 M4-2950 F (updated 11/9/11)
CALLAN TECHNOLOGY-SEM-MT30F4-39 M4-2950 U
CALLAN TECHNOLOGY-SEM-MT30F4-25 M4-2950 S
CALLAN TECHNOLOGY-SEM-MT30H4-65 M4-2951 L
CALLAN TECHNOLOGY-SEM-MT30H4-44 M4-2951 I
CALLAN TECHNOLOGY-SEM-MT30H4-33 M4-2951 C
CALLAN TECHNOLOGY-SEM-MT30H4-22 M4-2951 E
CALLAN TECHNOLOGY-SEM-MT30M4-59 M4-2951 K
CALLAN TECHNOLOGY-SEM-MT30M4-48 M4-2951 J
CALLAN TECHNOLOGY-SEM-MT30M4-38 M4-2951 H
CALLAN TECHNOLOGY-SEM-MT30M4-24 M4-2951 G
CALLAN TECHNOLOGY-SEM-MT30R4-58 M4-2952 I
CALLAN TECHNOLOGY-SEM-MT30R4-46 M4-2952 B (updated 3/12/12)
CALLAN TECHNOLOGY-SEM-MT30R4-37 M4-2952 A
CALLAN TECHNOLOGY-SEM-MT30R4-25 M4-2952 F
CALLAN TECHNOLOGY-SEM-MT30U4-57 M4-2959 E
CALLAN TECHNOLOGY-SEM-MT30U4-48 M4-2959 F
CALLAN TECHNOLOGY-SEM-MT30U4-36 M4-2959 A
CALLAN TECHNOLOGY-SEM-MT30U4-26 M4-2959 G
CALLAN TECHNOLOGY-SEM-MT30Z4-85 M4-2959 H
CALLAN TECHNOLOGY-SEM-MT30Z4-61 M4-2959 B
CALLAN TECHNOLOGY-SEM-MT30Z4-37 M4-2959 A
CALLAN TECHNOLOGY-SEM-MT 30-系列電機等效物原裝進口
